Acrylic DT/DT

•

• Component
  Fiber	100%DT
  Base Fiber	100%DT
  Weight(g/m2)	550
  Thickness(mm)	2.3
  Density(g/cm3)	0.29
  Mean Air Permeability(m3/m2/min)	1.4-4.0
  Breaking Strength
  Longitudinal(N)	≥700
  Transverse(N)	≥650

• Elongation
  Longitudinal(N)(%)	20
  Transverse(N)(%)	35
  Operating Temperatures
  Continuous(℃)	≤125
  Surge(℃)	140
  Surface Treatment	Heat set, singed calengered
  Applications	Dust removal in non-ferrous metal processing and smelting operations, as well as larger-scale dust collection applications.

Aramid MX/MX

•

• Component
  Fiber	100%MX
  Base Fiber	100%MX
  Weight(g/m2)	550
  Thickness(mm)	2.3
  Density(g/cm3)	0.24
  Mean Air Permeability(m3/m2/min)	1.6-4.0
  Breaking Strength
  Longitudinal(N)	≥800
  Transverse(N)	≥1000

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	35
  Operating Temperatures
  Continuous(℃)	≤200
  Surge(℃)	250
  Surface Treatment	Heat set, singed calengered
  Applications	Dust removal in high-temperature environments such as boilers, cement kiln heads, and steel mills.

Polyester PET/PET

•

• Component
  Fiber	100%PET
  Base Fiber	100%PET
  Weight(g/m2)	550
  Thickness(mm)	1.8
  Density(g/cm3)	0.29
  Mean Air Permeability(m3/m2/min)	1.4-4.0
  Breaking Strength
  Longitudinal(N)	≥1000
  Transverse(N)	≥1400

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	35
  Operating Temperatures
  Continuous(℃)	≤120
  Surge(℃)	150
  Surface Treatment	Heat set, singed calengered
  Applications	Dust removal under normal operating conditions, such as in coal mills.

Antistatic Polyester PET/PET

•

• Component
  Fiber	PET+Stainless
  Base Fiber	100%PET
  Weight(g/m2)	550
  Thickness(mm)	1.8
  Density(g/cm3)	0.29
  Mean Air Permeability(m3/m2/min)	1.4-4.0
  Breaking Strength
  Longitudinal(N)	≥1000
  Transverse(N)	≥1400

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	35
  Operating Temperatures
  Continuous(℃)	≤120
  Surge(℃)	150
  Surface Treatment	Heat set, singed calengered
  Surfacerdsistance	102Ωcm
  Applications	Dust removal in conventional high-temperature electrostatic environments, such as coal mills and dust collectors.

Polyphenylene Sulfide PPS/PPS

•

• Component
  Fiber	100%PPS
  Base Fiber	100%PPS
  Weight(g/m2)	550
  Thickness(mm)	1.9
  Density(g/cm3)	0.28
  Mean Air Permeability(m3/m2/min)	1.4-4.0
  Breaking Strength
  Longitudinal(N)	≥800
  Transverse(N)	≥1200

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	55
  Operating Temperatures
  Continuous(℃)	≤160
  Surge(℃)	190
  Surface Treatment	Heat set, singed calengered
  Applications	Dust removal from low-oxidizing flue gases in industries such as coal-fired boilers, waste incineration, metal smelting, and chemical processing.

Composite PPS+PTFE/PTFE

•

• Component
  Fiber	PPS+PTFE
  Base Fiber	100%PTFE
  Weight(g/m2)	550
  Thickness(mm)	1.8
  Density(g/cm3)	0.31
  Mean Air Permeability(m3/m2/min)	1.5-4.0
  Breaking Strength
  Longitudinal(N)	≥800
  Transverse(N)	≥1200

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	55
  Operating Temperatures
  Continuous(℃)	≤160
  Surge(℃)	190
  Surface Treatment	Heat set, singed calengered
  Applications	Dust removal from low-oxidizing flue gases in industries such as coal-fired boilers, waste incineration, metal smelting, and chemical processing.

Composite P84/PTFE

•

• Component
  Fiber	100%P84
  Base Fiber	100%PTFE
  Weight(g/m2)	550
  Thickness(mm)	2.1
  Density(g/cm3)	0.24
  Mean Air Permeability(m3/m2/min)	2.0-4.0
  Breaking Strength
  Longitudinal(N)	≥700
  Transverse(N)	≥1100

• Elongation
  Longitudinal(N)(%)	10
  Transverse(N)(%)	15
  Operating Temperatures
  Continuous(℃)	≤240
  Surge(℃)	260
  Surface Treatment	Heat set
  Applications	Dust removal from flue gases with moderate corrosion levels, such as those from chemical plants, metal smelting facilities, waste incineration plants, and cement kiln exhausts.

PTFE/PTFE

•

• Component
  Fiber	100%PTFE
  Base Fiber	100%PTFE
  Weight(g/m2)	750
  Thickness(mm)	1.3
  Density(g/cm3)	0.58
  Mean Air Permeability(m3/m2/min)	1.2-4.0
  Breaking Strength
  Longitudinal(N)	≥600
  Transverse(N)	≥650

• Elongation
  Longitudinal(N)(%)	35
  Transverse(N)(%)	55
  Operating Temperatures
  Continuous(℃)	≤240
  Surge(℃)	260
  Surface Treatment	Heat set
  Applications	Dust removal from high-temperature flue gases with high corrosion potential, such as those from chemical plants, coal-fired boilers, waste incineration facilities, and non-ferrous metal smelters.
